*X, Z, Y, A four axis control, Y and A axis names and types can be defined.
*1ms interpolation cycle, with control accuracy of 1 μ m or 0.1 μ m optional.
*The maximum speed is 60m/min (24m/min at 0.1 μ m).
*Adapting to servo spindles can achieve continuous spindle positioning, rigid tapping, and rigid thread processing.
*Built in multiple PLC programs, the currently running PLC program can be selected.
*Supports statement based macro code programming and macro program calls with parameters.
*Supports metric/imperial programming, with automatic tool alignment, automatic chamfering, and tool life management functions.
*Support Chinese and English display, selected by parameters.
*Equipped with USB interface, supporting USB file operation, system configuration, and software upgrade
*1-channel 0V~10V analog voltage output, supporting dual spindle control.
*1-channel handwheel input, supporting handheld units.
*28 points for input/24 points for output.
